The advanced signal processing product compatible with all GNSS constellation frequencies is a flexible and high-end testing tool.
RpsGnsSdr real-time software receiver is an advanced signal processing product compatible with all GNSS constellation frequencies, and is also a flexible and high-end testing tool. It provides an advanced development and verification platform for GNSS navigation receivers for researchers and engineers in the field of GNSS, which can assist users in the development of new receivers and complex algorithm research, including multipath and false signal evaluation, interference monitoring and ionospheric impact assessment, weak signal research, and IMU probe merging.
For non professional or GNSS beginners, we provide sample configurations of various applications to ensure that users can complete the correct configuration upon first contact, thus completing simple operations and experiments.
兼容全GNSS星座頻率的先進信號處理產品，同為一款靈活、高端的測試工具。
The scripted editing ability of the testing plan planning function and testing process allows users to plan and design the testing plan according to the testing requirements before the experiment, and edit the testing process. Users can manage and configure the testing scenarios and processes according to the testing needs of different receivers and different testing tasks and objectives, and use them as different testing templates.
Perform manual or batch Test automation based on test scenarios and test processes, and have one click Test automation function for user terminal technical indicators.
After each test project is completed, it can automatically analyze and evaluate the test data and generate test reports, with the function of automatic analysis and evaluation of user terminal technical indicators.
Multiple testing and evaluation modes are available, including automatic, manual, and single mode.
Real time analysis and evaluation of test data, capable of analyzing and comparing test data in real time, completing functional and performance indicators such as pseudo range measurement accuracy, positioning accuracy, channel consistency, bit error rate, etc., and automatically generating data processing reports.
The real-time analysis and evaluation function of test data allows for knowing the statistical results of indicators without waiting until the end of the test, facilitating the timely termination of problematic receiver tests and saving testing time.
Comprehensive display function: It can comprehensively display various information such as work status, simulation scenarios, positioning results, data processing reports, etc. in various forms such as data, tables, graphics, etc.
Database management function, which can automatically classify, store, query, and count simulation and test data, and has automatic data storage and retrieval functions.
Equipped with automatic evaluation of test results and automatic generation, printing, and export of test reports.兼容全GNSS星座頻率的先進信號處理產品，同為一款靈活、高端的測試工具。
|
支持信號頻點 |
|
|
BDS |
B1、B2、B3、S（含北斗三號） |
|
GPS |
L1、L2、L5 |
|
GLONASS |
L1、L2、L3 |
|
Galileo |
E1、E5 |
|
信號通道數目 |
|
|
接收信號通道≥64個（可通過升級GPU進行擴展），具備自動和手動兩種通道分配模式 |
|
|
導航信號處理 |
|
|
捕獲靈敏度 |
優于-140dBm |
|
跟蹤靈敏度 |
優于-145dBm |
|
偽距測量精度 |
≤0.01m |
|
載波相位測量精度 |
≤0.01周 |
|
水平定位精度 |
≤10m（95%） |
|
垂直定位精度 |
≤10m（95%） |
|
測速精度 |
≤0.1m/s（95%） |
|
接收信號動態 |
0～8000m/s |
|
物理特性 |
|
|
整機尺寸 |
標準2U高度19英寸上架式機箱 |
|
整機重量 |
≤4kg |
| 仿真信號規模 | |
| 衛星通道數量 | |
| 多徑信號數量 | |
| 信號精度 | |
| 偽距精度 | |
| 偽距變化率精度 | |
| 通道一致性 | |
| 信號動態 | |
| 仿真高程 | |
| 相對速度 | |
| 相對加速度 | |
| 相對加加速度 | |
| 外部軌跡實時性 | |
| 信號延遲 | |
| 數據更新率 | |
| 信號質量 | |
| 雜波抑制 | |
| 諧波抑制 | |
| 信號電平 | |
| 電平調節范圍 | |
| 電平調節步進 | |
| 物理和電氣性能 | |
| 整機尺寸 | |
| 整機重量 | |
| 電源、功耗 | |
